133819-01 3500/60 Bently RTD/TC Temp I/O Module

The **133819-01** is part of the **Bently Nevada 3500 Series**, specifically the **3500/60** module, which is designed for monitoring temperature inputs from RTDs (Resistance Temperature Detectors) and thermocouples (TCs). Bently Nevada is known for its condition monitoring and asset protection solutions, particularly in industrial and mechanical systems.

### Key Features of the 3500/60 RTD/TC Temperature I/O Module

1. **Input Types**: The 3500/60 module can accept signals from various types of temperature sensors:
– **RTDs**: Common types such as PT100 and PT1000.
– **Thermocouples**: Various standard thermocouple types (e.g., J, K, T, E, N, R, S, B).

2. **Multiple Channels**: The module typically supports multiple input channels, allowing it to read and monitor several temperature sensors simultaneously.

3. **High Accuracy and Resolution**: The module is designed for accurate temperature measurements, making it suitable for critical industrial applications where precise temperature monitoring is required.

4. **Alarm and Trip Functions**: The module can be configured to trigger alarms or trips if temperature readings exceed predefined thresholds, providing important safety and maintenance notifications.

5. **Diagnostics and Health Monitoring**: The 3500/60 module includes built-in diagnostics to monitor the health of connected sensors and itself, helping to identify faults and enabling proactive maintenance.

6. **Integration with 3500 System**: This module integrates seamlessly with the 3500 Series monitoring system, which is used for real-time monitoring and analysis of rotating machinery and other critical systems.

### Applications

– **Machinery Condition Monitoring**: Used in industries where monitoring the temperature of rotating equipment, such as turbines, compressors, and generators, is critical to ensuring optimal performance and preventing failure.

– **Process Control**: Applicable in process industries (like oil and gas, chemical processing) for monitoring and controlling temperature in various production processes.

– **Critical Asset Protection**: Helps in protecting expensive machinery assets by providing early warnings of potential issues related to temperature fluctuations.

### Documentation and Support

To find specific operational details, installation instructions, and configuration guidelines for the 3500/60 module, refer to:

– **Bently Nevada Documentation**: Access user manuals, data sheets, and technical references through Bently Nevada’s official support resources.

– **Technical Support and Service**: Bently Nevada or authorized distributors can provide assistance with installation, troubleshooting, and maintenance of the 3500/60 module.

If you have more specific questions or need further assistance regarding the **133819-01 3500/60 Bently RTD/TC Temp I/O Module**, feel free to ask!
