ABB 3BSC610037R1 SD821 Power Supply Device

Description

Detailed introduction of ABB 3BSC610037R1 SD821 module

1. Product name, model, and brand

Product Name: Safety Door Monitoring Module or Input Module
Model: 3BSC610037R1 SD821
Brand: ABB
2. Main functions and application scenarios of the product

Main function: This module is a high-performance security door monitoring solution designed to ensure the safety of personnel and equipment in industrial environments. It can receive safety door switch signals and output control system interlocking through safety relays to achieve the purpose of monitoring the status of safety doors.
Application scenarios: Widely used in industries such as mechanical manufacturing, chemical engineering, and power, especially in automated production lines and process flows that require monitoring of safety door status.
3. Technical specifications and parameters of the product

Power supply: Dual power redundant input, DC (9-36) V, typical value is DC24V, power consumption is less than 4W.
Relay alarm output: With fiber optic link fault and power supply fault alarm output function, the contact capacity is DC48V/1A.
External dimensions: 132mm x 105mm x 52mm.
Shell protection level: IP30.
Installation method: 35mm DIN rail installation.
Working temperature range: -10 ℃ to 70 ℃ (optional wide temperature range is -40 ℃ to 85 ℃).
Relative humidity: ≤ 90% (non condensing).
4. Advantages and characteristics of the product

Advantages: Fast response speed, high reliability, easy installation, with redundant power input and relay alarm output function, improving the safety and stability of the system.
Features: This module adopts advanced technology and design concepts, which can meet the needs of various complex industrial environments. At the same time, it provides rich interface and configuration options, making it convenient for users to customize applications and development.
5. Applicable scenarios and limitations of the product

Applicable scenarios: Suitable for various automated production lines and process flows that require monitoring of safety door status, such as mechanical manufacturing, chemical, power and other industries.
Limitations: When using, it is necessary to pay attention to standardized wiring and routing to avoid interference from strong and weak electrical signals; At the same time, it should be ensured that the working environment complies with the specified temperature and humidity range of the product.
