ABB 5SHX0660F0002 thyristor module

Description

ABB 5SHX 0660F0002 thyristor module report

1、 Product Overview

ABB 5SHX 0660F0002 is a high-performance Silicon Controlled Rectifier (SCR) module designed for efficient and precise control of power electronic systems.

2、 Product features

High efficiency: Adopting advanced thyristor technology to ensure fast and efficient power control and conversion.
Wide input range: This module can adapt to different power input requirements and provide greater operational flexibility.
Efficient heat dissipation design: By optimizing the heat dissipation system, the operating temperature of the module is effectively reduced, and stability and reliability are improved.
Programmable function: supports users to achieve personalized control logic and algorithms through programming, meeting different application needs.

3、 Application field

Power electronic systems, such as AC speed controllers, power dimmers, and controllers.
Industrial heating system: Control heating elements such as resistance heaters and induction heaters.
Motor control: achieving precise speed regulation and start-up control of the motor.
Electric dimming system: used in lighting applications to adjust light brightness.
Power transmission and distribution: Optimize the distribution and regulation of the power system, and improve the efficiency of the power grid.
Welding equipment: Control welding current and voltage in equipment such as arc welding machines.
Power factor correction device: improves the power factor of industrial and commercial power systems.

4、 Specification parameters

Type: Semiconductor thyristor rectifier intelligent module
Model: 5SHX 0660F0002
Rated current: 60A
Controllable range: 0-100%
Trigger method: positive pulse, negative pulse, zero voltage switch
Control methods: analog quantity, digital quantity
Heat dissipation methods: air cooling, water cooling
Power supply voltage: 24-55VDC
Control signal voltage: 0-10V, 5-24V
Control signal current: 5-20mA
Switching frequency: 15-50kHz
Efficiency:>95%
Power factor:>0.95
Insulation level: Class B
Dimensions: 87mm x 46mm x 23mm
Weight: 0.14kg
Product certification: CE, UL, CQC
