ABB 5SHY6545L0001 AC10272001R0101 5SXE10-0181 thyristor module

Description

ABB 5SHY6545L0001 thyristor module is a high-performance power electronic component mainly used in power control and power conversion systems. The following is a detailed introduction to this module:

1、 Basic information
Model: 5SHY6545L0001
Brand: ABB
Type: Asymmetric Integrated Gated Thyristor (IGCT) Module
2、 Technical specifications
Maximum rated current: 6500 A
Maximum rated voltage: 4500 V
Maximum rated on/off loss: 30000 W
Maximum rated switching frequency: 1600 Hz
Maximum rated junction temperature: 175 ° C
Minimum rated gate pulse current: 10 mA
Minimum rated gate pulse voltage: 15 V
Number of cores: 1
Cooling method: water cooling
Module packaging: TO-247AB
Module weight: approximately 6 kg

3、 Application field
ABB 5SHY6545L0001 thyristor modules are widely used in situations that require high power and high voltage control, such as power transmission and distribution, industrial motor drive, renewable energy (such as wind and solar) conversion systems, rail transit power drive, and other fields.

4、 Product features
High performance: With the ability to withstand high currents and voltages, suitable for high-power power electronic systems.
High reliability: Adopting advanced packaging technology and materials to ensure long-term stable operation.
Easy to control: By integrating gate control technology, precise and fast switch control can be achieved.
Good heat dissipation effect: adopting water-cooled heat dissipation method effectively reduces module temperature rise and improves service life.
5、 Purchasing and Consulting
The price of ABB 5SHY6545L0001 thyristor module varies due to factors such as supplier and order quantity. Please consult relevant suppliers for specific prices. Before purchasing, it is recommended to request samples from the supplier for testing to ensure that the product meets actual needs.

In addition, for more detailed information, technical documentation, and usage guidelines about this module, it is recommended to directly visit the ABB official website or contact an ABB authorized dealer for access.

6、 Precautions
When using the ABB 5SHY6545L0001 thyristor module, please be sure to follow the relevant safety operating procedures to ensure the safety of personnel and equipment.
Please select a suitable cooling system according to actual needs to ensure stable operation of the module under rated conditions.
During installation and maintenance, please follow the manufacturer’s instruction manual for operation.
