Acquisition AL81G A/D Converter Board

Description

The Acquisition AL81G module is a powerful and highly flexible electronic device that plays a crucial role in various application scenarios. The following is a detailed introduction to this module:

1、 Basic functions and characteristics

The Acquisition AL81G module is mainly responsible for the acquisition and conversion of analog signals. It can receive analog signals from sensors or other external devices and convert them into digital signals for use in subsequent digital processing systems. This feature makes the module widely applicable in industrial automation, data acquisition, monitoring and control systems.

The characteristics of this module are mainly reflected in the following aspects:

Diverse input range: Supports various input ranges such as 125mV, 250mV, 500mV, and 1V, meeting the acquisition needs of different signal strengths.
High bandwidth and sampling rate: Provides a peak to peak bandwidth of DC-350MHz, as well as a sampling rate of up to 1GS/s, ensuring signal accuracy and real-time performance.
Rich triggering and control functions: supporting pre triggering, post triggering, delayed sampling, and automatic rearming, providing flexible support for complex sampling needs.
Large capacity memory and DSP support: Equipped with 64MSample onboard sampling memory, and supporting DSP functions such as interpolation and programmable peak detector to enhance data processing capabilities.
2、 Importance in AL81G system

In the AL81G system, the Acquisition AL81G module plays a crucial role. It is not only a bridge between the system and external analog signals, but also a key link to ensure accurate signal acquisition and conversion. The high-performance characteristics of this module enable the AL81G system to process various complex analog signals, thereby achieving precise monitoring and control of industrial processes.

In addition, the Acquisition AL81G module also supports multiple interface types and communication protocols, allowing the AL81G system to efficiently exchange and share data with other devices, thereby improving the integration and intelligence level of the entire system.

3、 Technical specifications and interface types

The technical specifications of the Acquisition AL81G module include but are not limited to: input impedance of 50 ohms, 8-bit accuracy, multiple sampling rate options (such as 1000, 500, 250, and 100MS/s), etc. These specifications ensure the high performance and flexibility of the module.

In terms of interface type, this module uses BNC connectors for analog signal input and trigger input/output. This connection method is stable and reliable, suitable for various industrial environments. At the same time, the module also supports PCI interface, facilitating high-speed data transmission with computers or other digital processing systems.

4、 Power consumption and other information

In terms of power consumption, the Acquisition AL81G module has fully considered energy efficiency issues in its design. It adopts advanced power management technology and low-power devices to ensure stable performance during long-term operation.

Overall, the Acquisition AL81G module is a high-performance and multifunctional analog input electronic module that plays a core role in the AL81G system. By accurately collecting and converting analog signals, this module provides strong support for industrial automation, data acquisition, monitoring and control systems.
