The reactance rate is defined as the ratio of the fundamental inductance of a series reactor to the fundamental capacitance of a capacitor. CC-PAOX01 51405039-275 increases the reactance rate by 1% step by step from 0, and a set of harmonic amplification factor Ish/Ilh variation curves with harmonic frequency can be obtained, as shown in Figure 7.

As the reactance rate increases, the parallel resonance frequency f0 moves towards the low-frequency direction. When the frequency is higher than the series resonant frequency f1, Ish/Ilh is always less than 1, meaning that the harmonics of the frequency higher than f1 will not be amplified. Therefore, as long as the appropriate reactance rate is selected for the lowest harmonic frequency in the system, so that the resonant frequencies f0 and f1 are lower than the main harmonic frequency, harmonic amplification problems can be avoided.

Near f1, Ish/Ilh reaches a minimum value, and CC-PAOX01 51405039-275 indicates that harmonics near this frequency are greatly suppressed. This is due to the series resonance of L and C, which presents a very small impedance to the harmonic of the resonant frequency, resulting in harmonic diversion.
