DSDO131 Digital Output Unit 57160001-KX

ABB DSDO131 Digital Output Unit 5716001-KX is a digital output unit manufactured by ABB. The following is a detailed introduction to the product:

1、 Product Overview

Product model: DSDO131 Digital Output Unit 57160001-KX

Manufacturer: ABB

Application: As an extension module for programmable logic controllers (PLCs) or control systems, used in industrial applications to provide additional output points.

2、 Product Features

High reliability: Using high-quality components and redundant design to ensure the normal operation of the system.

Flexibility: Supports multiple output types and quantities to meet different application requirements.

Usability: Provides clear wiring diagrams and easy to understand programming guides for easy installation and maintenance.

Diagnostic function: Equipped with LED indicator lights and diagnostic positions, it can easily identify faults.

3、 Product specifications

Output type: Relay

Output quantity: 8

Load current: 2A per output point

Power supply voltage: 24VDC

Working temperature:- 25 ° C to 70 ° C (-13 ° F to 158 ° F)

Storage temperature:- 40 ° C to 85 ° C (-40 ° F to 185 ° F)

Relative humidity: 5% to 95% (non condensing)

Protection level: IP20

Product size: 120mm x 45mm x 22mm (4.72 x 1.77 x 0.87 inches)

4、 Application Fields

Industrial automation: used to control production lines, machinery and equipment, etc.

Manufacturing: Providing precise control in various manufacturing processes.

Oil and gas: Key controls are implemented during the extraction, processing, and transportation of oil and gas.

Electricity: Monitoring and operating in power generation, transmission, and distribution systems.

Water and wastewater: Control equipment such as pumps and valves in water treatment plants.

Mining: Controlling various equipment and systems in mining operations.

5、 Typical applications

In the factory: control the conveyor belts, conveyors, and other automated equipment of the production line.

In petroleum refineries: control valves, pumps, and other process equipment.

In power plants: control circuit breakers, transformers, and other power generation equipment.

In water treatment plants: control water pumps, valves, and other water treatment equipment.

In food processing plants: control conveyors, packaging machines, and other food processing equipment.

6、 Summary

ABB DSDO131 Digital Output Unit 5716001-KX is a highly reliable, flexible, and easy-to-use digital output unit suitable for various industrial applications. It provides additional output points, supports multiple output types and quantities, and can meet different application needs. Meanwhile, its high reliability, ease of use, and diagnostic capabilities have made it widely used in the field of industrial automation.
