F7123 | HIMA | Analog voltage module

Description

F7123 | HIMA | Analog voltage module

1. .Many products are not yet on the shelves please contact us for more products
2. .If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation
3. .We have 16 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

The modern development of high-speed F7123 circuit architecture mainly uses this fully parallel ADC, but due to the limitations of power and volume, it is not practical to manufacture high resolution scintillation ADC.

A higher resolution semi-scintillation ADC or hierarchical ADC composed of two lower resolution scintillation ADCs is the main way to manufacture high-speed ADCs in the world today. Figure 2 shows the schematic diagram of an 8-bit two-stage parallel semi-scintillation ADC. The conversion process is divided into two steps:

The first step is coarse-quantization. The F7123 first converts the high 4-bit in parallel as the converted high 4-bit output, and then converts the digital output to D/A to restore the analog voltage.

The second step is to further refine and quantify. The F7123 subtracts the original input voltage from the analog voltage of the output of the D/A converter, and then performs A lower 4 full A/D conversion. The digital output of the two stage A/D converter is then paralleled as the total output. In this way, a little sacrifice is made in the conversion speed, but the contradiction of improved resolution and the number of components is solved.

• 📩Please contact us for the best price. Email: 【sauldcsplc@gmail.com】

• 🌐For more products, click here

📎📝Mailbox：sauldcsplc@gmail.com |F7123
www.abbgedcs.com | Qiming Industrial Control | Simon +86 13822101417
