F8650X | HIMA | External Hybrid input circuit form MODULE

Description

F8650X | HIMA | External Hybrid input circuit form MODULE

1. .Many products are not yet on the shelves please contact us for more products
2. .If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation
3. .We have 16 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

The F8650X  collector open circuit output is a+V high level. When the output OUT terminal is connected to the PLC input, the current flows in from the input terminal of the PLC and out from the common terminal of the PLC. This is the form of the source type circuit of the PLC, that is, the PNP collector open circuit output can only be connected to the source type or mixed type input circuit form of the PLC. The connection diagram is shown in Figure 11

It is precisely because of the diversity of F8650X  input module circuit forms and external sensor output signals that we need to fully understand the type of PLC input circuit and the form of sensor output signals before wiring the PLC input module. Only in this way can we ensure that the PLC input module wiring is correct and lay a good foundation for subsequent PLC programming and debugging work.
