F8650X | HIMA | Support OTG function with MicroUSB interface for export

Description

F8650X | HIMA | Support OTG function with MicroUSB interface for export

1. .Many products are not yet on the shelves please contact us for more products
2. .If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation
3. .We have 16 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

We provide considerate service and complete parts

① Promptly reply you within 24 hours；

② 100% quality assurance, 1-year warranty；

③ Best services, reasonable price；

④ Have been in the line for many years, has a good reputation；

⑤ We will ship the items within 3 working days after the payment is reached；

⑥ All the goods will be tested before shipment；

⑦ Packing in professional anti-static bag；

The above picture shows two USB HOST interfaces, F8650X reset/power/user buttons, and debugging serial ports. i. MX 6UL/6ULL integrates two USB controllers and both support USB OTG function. Here, one USB is led out through a MicroUSB interface and supports OTG function; The other USB port is extended to 4 USB HOST ports through the SMSC USB2514BI-AEZ USB Hub chip, as shown in the following figure.

The above diagram shows the 12V power input interface, 12V DC JACK input interface, and MicroUSB OTG interface. The MYB-Y6ULX motherboard is powered by 12V, and the F8650X circuit includes seven voltage thresholds: 12V, 5V, ISO 5V, 3.8V, 3.3V, 1.8V, and 3V (RTC power supply).

The TLV62130 DC/DC buck converter from TI is used for 12V to 5V and 12V to 3.8V conversion, which supports a maximum output current of 3A. The purpose of using DC/DC for F8650X is to improve power efficiency and reduce board power consumption; The 5V to 3.3V and 3.3V to 1.8V use LDO power supply with smaller ripple.
