GE H201Ti PDF

Description

GE H201Ti PDF

1. .Many products are not yet on the shelves please contact us for more products
2. .If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation
3. .We have 16 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

Two wires – Serial Data (SDA) and Serial Clock (SCL).

·Each device has a unique address recognition and can function as a transmitter or receiver.

·Multiple hosts of GE H201Ti may cause bus arbitration issues. When multiple hosts simultaneously attempt to occupy the bus and initiate bus transmission of data, it is called bus contention. I2C uses bus arbitration to determine which host controls the bus.

·The validity requirement of data bits: The data on the SDA line must remain stable during the high-level period of the clock. The high or low level state of the data line can only be changed when the clock signal of the SCL line is low.

·Start and stop conditions: One scenario is when the SCL line is high and the SDA line switches from high to low, indicating the start condition. When SCL is at high level, the SDA line switches from low level to high level to indicate a stop condition.

·The start and end signals of GE H201Ti are both sent by the host. After the start signal is generated, the bus is in an occupied state, and after the termination signal is generated, the bus is in an idle state.

·After transmitting one byte of data, the sender will wait for a certain amount of time for the receiver’s response signal. The receiving end sends a response signal to the sending end by pulling down the SDA data line to remind the sending end that I have completed the acceptance and the data can continue to be transmitted. Then, the sending end can continue to send the data.
