Place the module power supply at a height of 25mm above the grounding plate. The IS215VPROH1BD grounding plate is made of aluminum or copper plate. The output common terminal and AC input ground terminal of the module power supply are directly connected to the grounding plate, and the grounding wire should be thick and not longer than 50mm.

Use 16AWG copper wire to make a 300mm long twisted pair, with one end connected to the power output and the other end connected in parallel with a 47 μ Connect the tantalum capacitor IS215VPROH1BD of F to the oscilloscope. The lead of the capacitor should be as short as possible, and the polarity should not be reversed. The ground wire of the oscilloscope probe should be connected to the ground ring as much as possible, and the oscilloscope bandwidth should not be less than 50MHz. The oscilloscope itself should be grounded for AC.

This article mainly introduces the testing methods and testing conditions for module power output ripple and noise. IS215VPROH1BD friends who have a need for such knowledge can take a few minutes to read this article, and I believe you will definitely find the knowledge you want from it.
