KOLLMORGEN 66WKS-P310/90-B

Description

KOLLMORGEN 66WKS-P310/90-B

1. .Many products are not yet on the shelves please contact us for more products
2. .If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation
3. .We have 16 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

The 66WKS-P310/90-B is a retired drive from the 60wks Analog Servo Amplifier Series retired by Kollmorgen. It features a 3 X 80 – 220/50 … 60Hz + max. 10% rated supply voltage and a 310 V rated DC-link voltage. The 66WKS-P310/90-B can hold a ballast circuit pulse power of 5.4 kW and a 200 W ballast circuit continuous power reading.

The 66WKS-P310/90-B model is designed by Kollmorgen to provide an energy-efficient and cost-effective motion control system for various industrial sectors. The 66WKS-P mains supply unit is designed to take power directly from the industrial 3-phase main supply unit via an isolating transformer. Some of the typical applications of power supply units are machine tools, printing machines, and textile machines. The rated mains supply voltage for the unit is 3 × 80 – 220 V AC supply unit. The input voltage frequency of the unit is 50 – 60 Hz. The rated voltage of 310 VDC generated by the supply unit is then used to operate the mains supply unit. The 66WKS-P mains supply unit is equipped with an integral ballast circuit and an external ballast resistor. The unit operating on the phenomena of natural convection consumes the rated current of 30 A, and the unit operating on the phenomena of forced convection, the unit consumes 90 A of rated current. The undervoltage threshold of the unit is 110 V. The ballast circuit operates at the rated voltage of 380 V and the ballast resistor dissipates the continuous power of 375 W (with natural convection).
