MOLEX SST-PB3-CLX-RLL Backplane Module

Description

Detailed introduction of MOLEX SST-PB3-CLX-RLL module

1、 Product Overview
The MOLEX SST-PB3-CLX-RLL module is a high-performance communication module designed specifically for industrial automation, particularly suitable for seamless integration with Rockwell Automation’s ControlLogix system. This module is designed and manufactured by Molex, aiming to meet the demand for efficient and reliable communication in industrial environments.

2、 Functional characteristics
Communication function:
The SST-PB3-CLX-RLL module provides communication with the ControlLogix system, allowing for data exchange between the ControlLogix controller and other external devices. This data exchange covers various types of information such as input/output data, status information, and commands.
This module supports Profibus DP master and slave modes, enabling efficient data exchange and communication with other PROFIBUS compatible devices.
Stability and reliability:
Designed for industrial environments with good stability and reliability. Its average time between failures can reach 30000 to 50000 hours, and it can operate stably for a long time under harsh conditions.
This module is equipped with a PROFIBUS D-sub female module with 9 pins for communication, ensuring the stability and accuracy of data transmission.
Flexibility and versatility:
Provide multiple communication interfaces and protocol options to meet different application needs. In addition to Profibus DP, it may also support other common industrial communication protocols.
The PROFIBUS scanner, available for Allen Bradley 1756 backplane systems and Honeywell PlantScape systems, helps enable communication links between CLX processors and remote I/O devices located on the PROFIBUS network.
Easy to integrate and manage:
Usually seamlessly integrated with ControlLogix systems, it can be easily installed in ControlLogix racks and set up and managed through corresponding software configurations.
Attached is the “Additional Configuration File” (AOP), which allows for easy integration into the ControlLogix system using RSLogix 5000 software.
Fault diagnosis and display:
Equipped with an LCD panel and three LED indicator lights (used to display communication, system, and normal status respectively), it helps users quickly identify the working status of the module and any potential issues.

3、 Application scenarios
The SST-PB3-CLX-RLL module is widely used in industrial automation systems that require efficient and reliable communication, including but not limited to the following scenarios:

Switching logic control: used to control the logical status of various switching devices.
Analog closed-loop control: plays an important role in situations where precise control of analog quantities (such as temperature, pressure, etc.) is required.
Data collection and monitoring: Real time collection and monitoring of various data in industrial processes.
Communication, networking, and acquisition control: Implement communication and networking control between devices in complex industrial automation networks.
4、 Applicable equipment and environmental limitations
Applicable equipment: mainly suitable for Rockwell Automation’s ControlLogix series PLC and other compatible industrial automation equipment.
Usage environment: Suitable for various industrial environments, including oil and gas factories, wastewater treatment facilities, steel mills, automobile manufacturing plants, etc. The working temperature range is between 0 and 60 degrees Celsius, and it can withstand a certain degree of vibration and impact.
5、 Summary of advantages and characteristics
High performance: Supports Profibus DP master and slave modes, with efficient data exchange capabilities.
High stability and reliability: Designed for industrial environments, able to operate stably for long periods of time under harsh conditions.
Flexible and versatile: Provides multiple communication interfaces and protocol options to meet different application needs.
Easy to integrate and manage: seamlessly integrated with the ControlLogix system for easy installation and configuration.
Visual fault diagnosis: equipped with LCD panel and LED indicator lights, convenient for fault diagnosis and status monitoring.
6、 Pictures or charts to assist in explanation
As providing images or charts directly is not feasible in this text answer, it is recommended to visit the official website of Molex or relevant industrial automation forums to obtain detailed images and technical specifications of the SST-PB3-CLX-RLL module, in order to have a more intuitive understanding of its appearance and specific parameters.
