NI SCXI-1193 Multiplexer switch module

Description

The NI SCXI-1193 module is a high-density, 32 channel RF multiplexer switch module produced by National Instruments in the United States. The following is a detailed introduction to this module:

1、 Basic Overview
Product model: NI SCXI-1193
Manufacturer: National Instruments (NI)
Main purpose: This module is mainly used for switching and multiplexing multiple signals in measurement and testing applications, especially suitable for processing high-frequency signals.
2、 Main features
High density and multi-channel:
Provides 32 channels, allowing users to quickly switch between multiple measurement channels, thereby achieving multiplexing of multiple signal sources.
Using high-density push type MCX connectors for discrete but easy to manage wiring.
High bandwidth and high-frequency signal processing capability:
Capable of withstanding signal frequencies from DC to over 500MHz, suitable for measuring and analyzing high-frequency signals.
Flexible configuration mode:

It can be configured with various topology structures, such as four 8 x 1 multiplexers, four 4 x 1 terminated multiplexers, dual 16 x 1 multiplexers, dual 8 x 1 terminated multiplexers, 32 x 1 multiplexers, 16 x 1 terminated multiplexers, and independent modules.
It can be configured through programming to meet different application requirements.
High performance and durability:
The relay is made of silver palladium and gold, which has high durability and reliability.
Cables have high flexibility and durability, suitable for various industrial and laboratory environments.
Modular design:
As part of the SCXI series, this module is compatible with other SCXI modules and devices through modular design, allowing users to flexibly configure and expand the system according to their needs.
3、 Application scenarios
Mainly used for integrating high-frequency devices, such as PXI-5404 frequency generators and PXI-5112 high-speed digitizers.
Suitable for various measurement and testing applications, such as data acquisition, vibration analysis, temperature measurement, etc.
4、 Technical specifications
Dimensions: 1.2 x 6.8 x 7.8 inches
Weight: 2 ounces
Connector: 36 MCX sockets for I/O connectors and 2 SMB sockets for triggering connectors
Maximum scan rate: 100 operations per second
Working temperature range: Recommended from 0 ° C to 50 ° C, stored at -20 ° C to 70 ° C
Humidity range: 5% to 85% (non condensing)
5、 Summary
The NI SCXI-1193 module is a powerful, flexible, and versatile high-density RF multiplexer switch module. Its high bandwidth, multi-channel, flexible configuration, and high performance make it widely applicable in various high-frequency signal processing and measurement applications.
