PFCL201CD 20KN | ABB | Encoder modification parameters

Description

PFCL201CD 20KN | ABB | Encoder modification parameters

1. .Many products are not yet on the shelves please contact us for more products
2. .If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation
3. .We have 16 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

From a macro perspective, the PFCL201CD 20KN has set up three layers of pages. The top layer is the work page, which is where the system operates normally; The second layer is the parameter selection page, where users select the parameters that need to be modified; The third layer is the parameter modification page, where users can use the encoder to modify the size of parameters. The speed of the encoder rotation corresponds to the speed of the set value change, and users can also zero and calibrate the system here. Due to the fact that the tension sensor measures the weight of the roller and the total tension of the coil, while zeroing is done by first measuring the weight of the roller; Calibration is the use of a signal obtained by hanging a known weight code on a roller, so that the tension of the coil can be accurately measured.

PFCL201CD 20KN  tension control process can be divided into four stages: preparation stage, start-up stage, operation stage, and shutdown stage. Before t0, it was the preparatory stage, from t0 to t1 was the start-up stage, from t1 to t2 was the operational stage, from t2 to t3 was the shutdown stage, and after t3, the system entered the preparatory stage again, while T0 was the tension set by the user. Users can complete the control process by setting the parameters in the table. The preparatory stage can be said to be the waiting stage. At this time, users need to prepare the coil material, and the system has a certain preparatory output for preheating the magnetic powder.
