PFCL201CE-50KN | ABB | Zero tension alarm module

Description

PFCL201CE-50KN | ABB | Zero tension alarm module

1. .Many products are not yet on the shelves please contact us for more products
2. .If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation
3. .We have 16 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

After completing the reading of the input signal, the PFCL201CE-50KN needs to digitally filter the tension sampled signal, compare it with the tension value set by the user, and control the output PWM wave through PID adjustment. The length of the material can be calculated by combining the time collected by Timer 2 with parameters such as the roller diameter and material thickness set by the user. When the receiving reel receives a user’s request, if the full material alarm is activated, it can remind the user to replace the reel; Similarly, the low material alarm can be activated during unwinding. When the measured PFCL201CE-50KN digital quantity is very small, if the zero tension alarm is enabled, it can remind the user of abnormal operation.

When the program is running, we can create a storage space in FLASH to save the user set parameters here. Every time we start up, we can first read the parameters from this storage space, so that the system can not only run accurately, but also reduce a lot of setup hassle. However, during the operation of the system, there may also be a sudden power outage. At this time, it is necessary to save the diameter of the roll (the diameter of the unwinding or unwinding roll), and the roll diameter does not need to be calculated from the initial value when starting up the next time. The PFCL201CE-50KN is equipped with a programmable voltage monitor, where the voltage monitoring interrupt function can be enabled, so that the current roll diameter can be stored using the on-chip blank FLASH in the moment of power failure. Table 1 shows some parameters that users need to set during the tension control process.
