REF542PLUS | ABB | driver transformer Feeder device

Description

REF542PLUS | ABB | driver transformer Feeder device

1. .Many products are not yet on the shelves please contact us for more products
2. .If there is any inconsistency between the product model and the picture on display, the model shall prevail. Contact us for the specific product picture, and we will arrange to take photos in the warehouse for confirmation
3. .We have 16 shared warehouses around the world, so please understand that it can sometimes take several hours to accurately return to you. Of course, we will respond to your concerns as soon as possible

REF542PLUS  can generate oscillation pulses of 120kHz, output from pins 3 and 4 of the module, and drive the switching transistors VT4 and VTs to work through the excitation transformer T. The 9 pins of CF8865 are the output voltage adjustment terminals, and RPi is the adjustment potentiometer. By adjusting the pin, the output voltage value can be changed. The 8 pins are the input terminals of the output voltage error sampling voltage. l. The two pins are the input terminals for sampling and controlling the fluctuation of the mains voltage input. As the 3.4 pin of CF8865 not only pushes a pulse to the excitation transformer Tz output to make VT4 and VTs conduct and cut off, but also drives the conduct and cut off of vrl through another winding. When the mains voltage fluctuates, the rectified output 300V DC voltage will also fluctuate. As a result, the amplitude of the pulse formed by VTI conduction and cutoff at both ends of the primary winding of TI will also fluctuate. After coupling to the secondary, the amplitude of the negative voltage generated by VD4 rectification will also transition, causing a change in the potential difference between pins 2 and 1. After internal path detection, the width of the push pulse output by pins 3 and 4 will be controlled, The ultimate goal is to achieve voltage stabilization control for output voltage fluctuations caused by mains power fluctuations.
