RELIANCE Y-3023-2-H00AA motor

Description

The RELIANCE Y-3023-2-H00AA motor is a high-performance brushless servo motor with features such as precise control, high responsiveness, programmability, and reliability. Here is a detailed description of the motor:

1. Basic Parameters

* **Brand**:RELIANCE(瑞恩)，Allen-Bradley Series
* **Part number/Catalog number**：Y-3023-2-H00AA
* **Product type**：Brushless servo motor
* **Frame size**：3023
* **Motor winding**：ke Indicator 230V AC
* **Dimensions**：140 x 80 x 80 millimeters (5.57 x 3.15 x 3.15 inches)
* **Shaft diameter**：16 millimeters (0.63 inches)
* **Shipping weight**：3.9 kilograms (8.7 pounds)

2. Technical Features

1. **Precise Control**:
– The Y-3023-2-H00AA motor can achieve high-precision control of position, speed, and acceleration. By receiving instructions, the motor can quickly and accurately execute actions, thereby improving production efficiency and product quality.

2. **High Responsiveness**:
– This servo motor has a fast response speed, allowing it to quickly change its position or speed within a short period of time. This makes it excel in applications where quick movements are required, such as CNC machines and packaging machinery.

3. **Programmability**:
– The Y-3023-2-H00AA servo motor is typically equipped with a programmable controller, allowing users to customize the motor’s parameters and functions according to their specific needs. By programming, users can achieve flexible control over the motor’s position, speed, and acceleration, further expanding its application range in various fields.

4. **Reliability**:
– This servo motor uses high-quality materials and advanced manufacturing processes, resulting in a long service life and stable performance. Additionally, the motor is equipped with various protection functions, such as overload protection and short-circuit protection, ensuring a quick response in emergency situations and device safety.

5. **Easy Maintenance**:
– The Y-3023-2-H00AA servo motor is designed with ease of maintenance in mind. Users can ensure long-term stable operation by regularly checking the motor’s operating status, cleaning, and maintaining it.

III. Technical Specifications

* **Maximum radial (FR) load**:35 kg
* **Operating speed**:4500 rpm
* **Number of poles**:8 poles
* **Thermal resistance**:0.85 cubic centimeters/watt
* **Number of optical encoder lines**:2000 P/R resolution, with direction signal
* **Encoder power supply**:5 volts DC
* **Enclosure protection rating**:IP43
* **Operating temperature range**:0 to 40°C (32 to 104°F)

IV. Application Fields

The RELIANCE Y-3023-2-H00AA motor is widely used in various industrial automation fields, including but not limited to:

* **Industrial Automation**: controls the movement of production lines, such as assembly lines and packaging machinery.
* **CNC Machines**: controls the precise movement of tools and work tables.
* **Printing and Packaging**: provides high-precision position and speed control for fine printing and packaging processes.
* **Medical Equipment**: used in medical imaging equipment and surgical robots, providing precise motion control.
* **Aerospace**: plays a critical role in flight control systems, ensuring the stability and precise navigation of aircraft.
* **Robotics**: used in various industrial and service robots, enabling complex motion and operation tasks.
* **Electronic Manufacturing**: used in semiconductor manufacturing and electronic device assembly for high-precision positioning and movement.
* **Test and Measurement**: drives precise test fixtures and measurement equipment in laboratories and test equipment.
* **Automated Storage Systems**: controls the movement of conveyor belts and mechanical arms.
* **Energy Production**: may be used to control wind turbines and solar tracking systems.

5. Precautions

* The Y-3023-2-H00AA motor requires a servo drive to complete a servo drive positioning system. Allen-Bradley recommended servo drive models include 1398-DDM-019, 1398-DDM-020, 2093-AM02, 2094-AM02, or 2098-DSD-020.
* The system connection to the servo motor shaft should be rigid to prevent coupling, belt pulleys, or belts from slipping over time and causing shaft deterioration. The connection cable should be as short as possible.
* The motor should be used in a standard industrial environment and avoided exposure to high humidity or high ambient temperature.

In summary, the RELIANCE Y-3023-2-H00AA motor is a powerful and stable brushless servo motor that is widely used in various industrial automation fields.
